MIL-DTL-19803G
Delivery rate (room temperature)
4.4.1 Sampling.
4.4.1.1 Inspection lot.
4.4.1.1.1 Converter. An inspection lot size shall be expressed in units of one converter
made under essentially the same conditions and from the same materials and components. The
sample unit shall be one converter.
4.4.1.2 Sampling for tests and examinations of converters. The sample size, acceptance
criteria, tests, and examinations required for the converters shall be as specified in table I.
TABLE I. Test method, sample size, and acceptance criteria of the converters.
Inspection
Test method Sample size
Acceptance criteria
Visual examination
4.6.1.1
Every converter for
Reject all units with any
(See table II,
critical defects.
critical defects.
classification of defects)
Inspection level II for
Acceptance Quality Level of
minor defects.
2.5 defects per hundred units
for minor defects.
Dimensions
4.6.1.1.1
Inspection Level S-2
Acceptance number zero,
rejection number 1.
Permanent volumetric
4.6.2
Inspection Level S-4
Acceptance number zero,
expansion
rejection number 1.
Pressure tests
4.6.3
Every converter
Reject all defective units.
Filling time
4.6.4
Every converter
Reject all defective units.
Building time
4.6.5
Every converter
Reject all defective units.
Dielectric strength
4.6.6
Inspection Level S-2
Acceptance number zero,
rejection number 1.
Insulation resistance
4.6.7
Every converter
Reject all defective units.
Relief valve test
4.6.9
Every converter
Reject all defective units.
Sensing element
4.6.8.1
Every converter
Reject all defective units.
calibration (empty
converter)
Sensing element
4.6.8.2
Inspection level S-2
Acceptance number zero,
calibration (filled
rejection number 1.
converter)
Evaporation loss tests
4.6.10
Every converter
Reject all defective units.
Secondary overpressure
4.6.11
Inspection Level S-2
Acceptance number zero,
safety
rejection number 1.
Delivery rate (room
4.6.16.1
Inspection Level S-2
Acceptance number zero,
temperature)
rejection number 1.
13
