MIL-S-83492(USAF)
5 May 1977
SUPERSEDING
MIL-C-25570E(USAF)
13 March 1969
MILITARY SPECIFICATION
SURVIVAL KIT CONTAINERS, AIRCRAFT SEAT,
GENERAL SPECIFICATION, FOR
This specification is approved for use by all Departments and Agencies.
of the Department of Defense.
1. SCOPE
1.1 Scope. This specification covers the general requirements for rigid seat
style survival kit containers for aircraft equipped with ejection seats.
1.2 Classification. The survival kit containers shall be furnished in the
following types as specified (see 3.5 and 6.2):
Operation of deployment sensing cable assembly caused by man
Type I -
separating from seat
Type II - Operation of deployment sensing cable assembly caused by
canopy risers deploying from parachute pack.
APPLICABLE DOCUMENTS
2.1 Issues of documents. The following documents, of the issue in effect on
date of invitation for bids or request for proposal: form a part of this speci-
fication to the extent specified herein.
SPECIFICATIONS
FEDERAL
Plastic Material, Polyester Resin, Glass Fiber Base, Low
L-P-383
Pressure Laminated
MILITARY
Preservation-Packaging, Methods of
MIL-P-116
Surfaces Treatments and Inorganic Coatings for Metal
MIL-S-5002
Surfaces of Weapons Systems
MIL-W-5625
Webbing, Textile, Nylon, Tubular
Cable Assemblies: Aircraft, Proof Testing and Prestretching of
MIL-C-5688
MIL-C-6021
Castings, Classification and Inspection of
Terminal-Cable Assemblies, Swaged Type
MIL-T-6117
FSC 1660
