MIL-DTL-5886 Cylinder, Aircraft Oxygen, Low Pressure, NonshatterableThis specification covers low pressure storage cylinders for compressed gas with a working pressure of 450 psi for aerospace application.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16 - 17 - 18 - 19 - 20 - 21


MIL-DTL-5886H
TABLE IV. Cylinder characteristics
PIN
INTERNAL
WEIGHT
LENGTH
DIAMETER
NUMBER
VOLUME IN3
(Superseded
POUNDS
INCHES
INCHES
OF
Type)
(MIN)
(MAX)
(MAX)
(MAX)
OPENINGS
M5886-1 (A-6)
280
3.75
14.500
5.750
1
M5886-2 (B-3)
280
3.75
15.000
5.750
2
M5886-3 (D-2)
500
5.75
23.500
5.750
2
M5886-4 (F-1)
1000
10.00
18.000
10.125
2
M5886-5 (F-2)
1000
11.00
44.500
5.750
2
M5886-6 (G-1)
2100
18.00
24.500
12.562
2
M5886-7 (J-1)
18000
155.00
49.250
24.500
2
17
